Spreaders for medium trucks
Available in container sizes from 2.2 m³ up to 5.0 m³
ONE OH metal belt spreader or ONE OK rubber belt spreader, for medium trucks, suitable for salt, sand or grit. The hopper, fully welded to prevent vibrations, is made in AISI 304 stainless steel, providing load capacity without any deformation.
Get to know the One spreader
Metal belt: The feeding system is realized by an AISI 304 stainless steel chain with cross-bars. The chain is guided by toothed pinions that enables a constant traction maintaining a correct translation synchrony, without skidding.
Rubber belt: The feeding system is realized by a double layer natural rubber belt with polyester and nylon core. The traction roller that moves the rubber belt is crowned to avoid side deviations and tried to minimize skidding.
Auger: The feeding system is realized by an auger with variable pitch turn. The bottom of the feeding system is realized by an anti-abrasive rubber to enable the passage of bigger lumps avoiding the auger blockage.
The gritting machines of the One range are renowned for their excellent reliability, first-class service and attractive price-performance ratio. The excellent equipment finish and the use of tried-and-tested components are further proof of the great technical expertise built into our machines.
The high proportion of stainless steel ensures even the basic amenities for a long lifetime of the spreaders (Skid plates, spreader disc, feet sockets and all fasteners are in stainless steel). The device security cover is also made of stainless material.
- Large choice of container sizes
- Low container profile
- Low container centre of gravity
- Very short overhang of spreader unit
- Standard-compliant spreading precision test
- Eco hydraulic block
- State-of-the-art liquid salt technology
- Special paintwork and many stainless steel components
Metal belt feeding system
The feeding system is realized by metal belt an AISI 304 stainless steel with cross-bars. The chain is guided by toothed pinions that enable a constant traction, maintaining a correct translation synchrony, without skidding.
Rubber belt feeding system
The feeding system is realized by a double layer natural rubber belt with polyester and nylon core. The traction roller that moves the rubber belt is crowned to avoid side deviations and tried to minimize skidding.
The roller breaker enables a continuous material flow from the hopper to the spreading unit, breaking the salt lumps and thereby avoiding an uncontrolled drop. At the exit side of the chain or rubber belt feeding system, a hydraulically driven, transversal counter-rotating roller breaker with stainless steel blades is installed.
Standard Spreading system
The chute is realized in polyethylene HD (high density) with circular shape permitting excellent sliding features at low temperatures. The spreading disc with diameter 470 mm and max. spreading width 8m, is equipped with 6 blades realized in AISI 304 stainless steel for corrosion protection.
Premium Spreading system
The chute is realized in polyethylene HD (high density) with circular shape permitting excellent sliding features at low temperatures. The spreading disc with diameter 600 mm and max. spreading width 12m, is equipped with 6 blades realized in AISI 304 stainless steel for corrosion protection. Blades are adjustable according to adapt the material distribution to its granulometry.
Hydraulic Driving systems
Throughout the vehicle hydraulic system the features comply with the European Standards EN15431.
Auxiliary engine Driving systems
Driving through the two-cylinders Diesel or Petrol engine, air cooled.
Salt missing sensor
Optical Salt missing sensor with visualization on the driver’s cabin display
Automatic demount system
P1: Unloading system with galvanized telescopic feet with crank. Higher front feet for easy loading on vehicles provided with side panels.
P3: Automatic unloading system for tipper, with front rollers and feet fitting into the spreader. Unloading can be made automatically from the driver’s cab.
P4: Hook unloading system complete with slide, protection guard for the vehicle platform and adjustable height rear rollers.
The pre-wetting system is equipped with a volumetric pump directly coupled to the hydraulic motor, which is maintenance free. The Nitrile rotor does not need internal washing (only at the end of the season). Tanks constructed from sturdy and light-weight recyclable polyethylene. Solid/liquid ratio is regulated directly from the control box in the driver’s cabin.
Get to know more
Latest generation microprocessor control systems for all kind of spreaders, with maximum flexibility in programming and visualizing the different spreading parameters: width, asymmetry and dosage depending on the vehicle speed. Six different tools in all-in-one control box.
Ecosat has an integrated GSM/GPRS module (option) which enables operational data transmission. In case of bad coverage (e.g. tunnels) the data are logged and will be transmitted as soon as the connection is back.
Ecosat integrates (option) a multi-constellation GNSS receiver which supports GPS or GLONASS improving the localization performance in terms of accuracy, continuity, availability, and reliability.
The Ecosat stores daily operational reports and global counters which can be downloaded or printed via serial connection.
A serial connection between the infrared sensor and the Ecosat allows automatic changing of the spreading dosage based on the road temperature.
The Route-Replay is based on pre-defined geo-referenced spreading parameters settings uploaded on the EcoSat before the operation and used automatically during the mission relying on an enhanced positioning. The driver is guided by means of vocal and visual messages which show the road section already treated as well as the section that still has to be done. It is possible to exit from any pre-set route and re-entry at any point along the section.
On spreaders with electrical control of asymmetry, this function provides full control of the direction of spreading. The screen display varies according to the type of asymmetry: with or without feedback. 5 pre-set positions can be selected.
In this section of the working area, it is possible to monitor the level material in the tanks, the solid quantity in the hopper and also the fuel level (only for equipment with auxiliary engine).
The vehicle speed can be simulated from 5 to 90Km/h in steps of 5. This feature is useful when there is no tachometer connection, when the connection is damaged or when the spreader has to work while the vehicle is not moving.
The EcoTron control panel unit is characterised by its compact dimensions and high-resolution graphics display. The EcoTron performs sensor-based and monitoring of distance-dependent screw conveyor speeds and pump speeds, and also saves all relevant working data. A serial USB interface port is available for easy exporting of data.
Compact dimensions: Width 175 mm, Height 115 mm, Depth 65 mm.
Two rotary knobs with precise click-in positions.
Large colour display 95 mm x 55 mm, dimmable.
Enlarged display area if the quantity to be spread or the width of spread changes.
Simple and secure adjustment of the most important spreading parameters: Metering width and asymmetry.
Backlight function keys for secure operation of the main functions even under bad lighting conditions.
User-friendly control interface which presents all the important information in a clearly structured format - optimum design based the latest best practice.
Continuous recording all working data together with the overall information can be exported to an external storage medium (UBS stick) via the serial interface port.
Distance-dependent spreading by sensor-based monitoring of the screw conveyor speeds and pump speeds.
