GullyFlex C80

Effective cleaning and easy operation

The new Bucher GullyFlex C80 is designed to make maintenance of gullies easy and efficient by combining a flexible boom, a powerful vacuum pump and a large tank for debris.

Read more about the special features of the new Bucher GullyFlex C80 below.

Get to know the GullyFlex C80

Technology

Powerful specialist

Designed to make cleaning of gullies efficient and effective

The Bucher GullyFlex C80 vacuum system is securing jetting/suction/emptying capabilities, which are achieved with the suction hose mounted on the 300 degree rotation boom and the jetting reel at the rear.

The large 8 m3 tank is emptied by opening the end cover and tipping the tank by activating the single, multistage, front mounted ram.

Performance

Optimized design

Designed for ease-of-use by the operator

The GullyFlex C80 is a specialist at work, building on the technology of the Bucher range of sewer cleaning vehicles.

The CAN Bus system is operated with three push-button pannels and a display, controlling various functions such as boom direction, jetting pump, vacuum pump, inlet valve, lights, tank tilt, end cover open/close, lock for end cover and rear work lights.

One panel is located at the boom handle, one under the shelf, and one at the rear jetting reel. The display is located inside the operator's cabin.

Cost

Designed to be efficient

Gets the job done, at a low cost

The new Bucher GullyFLex C80 is fuel efficient, focused and flexible.

The fixed partition in the tank allows to carry clean water for jetting on one side, and sludge on the other side thus making the daily operation more efficient. Two available positions for the fixed partition are available to choose from to get the water / sludge volume configuration needed

The load-sensing hydraulic drive in the jetting and vacuum pumps delivers only the power needed for each task. This saves fuel and reduces the noise exposure time for the operator.

Safety

Tipping stability

Safety in focus

Frame made of steel and front mounted tipping cylinder. The tipping angle is 35 degrees, and the end cover opening is 70 degrees. When the tank is tipped, the Bucher GullyFlex C80 reaches a height of 5,411 mm.

Key specifications

Tank volume: 8 m³
Operating pressure: 0.5 bar
Tipping angle: 35 degrees
Opening angle: 70 degrees
Vacuum pump: Jurop DL125HDR 440 cfm (12,400 l/min)
Suction boom: back mounted with a 300 degree rotation and 5" suction hose

Key Features

Storage (option)

Accessories and options

Control panels

Tipping tank

Suction boom

Hygiene on the go

Shelves and cabinet

As an option, shelves and a cabinet can be mounted for storing accessories and gear safely. The easy access to equipment helps operators to get started - and move on to the next job faster.

It's all about the details

Make your workday easier and safer with the vice accessory as well as nozzle set and optional storage and safety equipment such as grid lifter, directional arrows, etc.

Automatic operation with the user-friendly control panels

Manage all functions needed for the job with the push button panels mounted on the boom, under the shelf, at the rear jetting reel and at the cabin. This provides a more intuitive way to operate the Bucher GullyFlex.

Easy unloading

Single, front mounted tipping cylinder, and stainless steel bottom inner liner for easier unloading. The tipping angle is 35 degrees, and the end cover opening is 70 degrees. When the tank is tipped, the GullyFlex reaches a height of 5,411 mm.

Simple and cost effective

The operation of the boom is manual with hydraulic balancing system and pneumatic pivot lock. The boom has a 5” hose and reaches -1200 mm down and +1800 mm up from level position and has a 300-degree rotation.

Mobile handwashing facility

Meet occupational health and safety requirements with the mobile hand wash facility. Operators can keep their hands clean during a working day by washing them with either cold or warm water.

Product options

GullyFlex C80 with
fixed partition

Two options for the position of a fixed partition to keep water and sludge separated.

Read more Read less

GullyFlex C80 with
additional equipment

Make your day more efficient with the addition of optional equipment such as a grid lifter, foldable directional arrows, suction hose, couplings. Each sold separately.

Read more Read less

GullyFlex C80 with
extra storage

Need more space for storing your equipment? You can add any of these storage options to meet your needs: cabinet, shelves, storages for safety fence, cone holder and cover hook holder.. If you need to hold stones or other large blocking objects, you can get the optional stick box. Each sold separately.

Read more Read less

GullyFlex C80 ready for
Bucher Connect

Monitor every unit, plan your routes efficiently and reduce downtime with Bucher Connect's fleet and jobs management, service materials, among other things.

Read more Read less
